Surly Ogre

Frameset

Frame

100% Surly Chromoly Steel, Natch tubing, double-butted main triangle, TIG welded, E.D. coated

Color

Orlok's Shadow

Fork

100% Surly Chromoly Steel, Natch tubing, double-butted tapered fork blades, TIG welded, E.D. coated

Components

Headset

Cane Creek 40

Seatpost Clamp

Surly Stainless 30.0

Seatpost

Promax SP-2016, 27.2 x 300mm

Stem

Promax DA-296

Grips/Bar Tape

Velo Black

Saddle

WTB Volt Medium

Handlebar

Salsa Bend

Drivetrain

Front Derailleur

N/A

Rear Derailleur

Shimano Deore M6100 SGS

Cassette

Shimano Deore M6100, 10-51t, 12spd

Chain

KMC X12 EPT Anti-Rust

Crankset

Shimano MT511, 30T

Shifter

Shimano Deore M6100

Brake Levers

Tektro HD-M275/HD-M276

Brake Calipers

Tektro HD-275/276, 2 piston

Bottom Bracket

Shimano MT501 BSA

Rotors

Tektro 160/160, 6-Bolt

Wheels

Front Tire

Surly ExtraTerrestrial 29 x 2.5" 60tpi, Tubeless Ready (Slate wall). Tubes installed, WTB TCS sealant included.

Rear Tire

Surly ExtraTerrestrial 29 x 2.5" 60tpi, Tubeless Ready (Slate wall). Tubes installed, WTB TCS sealant included.

Front Hub

Novatec QR 9 x 100mm, 32h, 6-Bolt

Rear Hub

Novatec TA 12 x 142mm, 32h, 6-Bolt

Spoke

14g Black

Rim

WTB ST i30 29", TCS 2.0, 32h

Weight

Complete Bike

30 lb 1 oz. for Medium

*Specifications are subject to change without notice

Frame Warranty

LIMITED WARRANTY

This Surly product is warranted against defects in materials and
workmanship for three years from the date of retail purchase of the
product, subject to the limitations detailed below. Save your dated
receipt for proof of purchase.

This warranty does NOT cover the following:

Damage due to improper assembly or follow-up maintenance or lack of skill, competence or experience of the user or assembler

Products that have been modified, neglected, used in competition or
for commercial purposes, misused or abused, involved in accidents or
anything other than normal use

Installation of components, parts or accessories not originally intended for or compatible with bicycle as sold

Damage or deterioration to the paint, surface finish, aesthetics or appearance of the product

Normal wear and tear

Labor required to remove and/or refit and re-adjust the product within the bicycle assembly

This limited warranty is expressly limited to the repair or
replacement of a defective product, at the option of Surly, and is the
sole remedy of the warranty. This limited warranty applies only to the
original purchaser of the Surly product and is not transferrable. This
warranty applies only to products purchased through an authorized dealer
or distributor. In no event shall Surly be liable for any loss,
inconvenience or damage, whether direct, incidental, consequential, or
otherwise resulting from breach of any express or implied warranty or
condition, of merchantability, fitness for a particular purpose, or
otherwise with respect to our products except as set forth herein.

This limited warranty gives the consumer specific legal rights, and
those rights and other rights may vary from place to place. This limited
warranty does not affect your statutory rights.

TO THE EXTENT NOT PROHIBITED BY LAW, THESE WARRANTIES ARE EXCLUSIVE
AND THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OR CONDITIONS
INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
