What hath Surly wrought this time?
The Surly Sorceress is a progressive steel trail hardtail built for riders who like their singletrack fast, loose, technical, and just a little bit rowdy. It’s the kind of bike that feels right at home diving into steep chutes, pumping through feature-rich trail, and charging rough descents with a big grin on your face.
At the heart of it all is Surly’s 100% Chromoly steel frame, built with Natch tubing and tuned specifically for Sorceress. That gives it the lively, springy ride feel steel fans love, while still delivering the kind of durability you want from a hardtail that’s going to be ridden properly. It has that classic steel character, just aimed squarely at modern trail riding rather than nostalgia.
The geometry is bang up to date too. A long front centre, slack head angle, and steep seat tube angle help Sorceress stay calm when the trail gets steep, efficient when the climb kicks up, and playful when the trail opens up. Add in generous standover clearance and room for longer droppers, and you’ve got a bike that encourages you to move around, get loose, and commit to the good line.
One of the more interesting tricks up its sleeve is Surly’s new DUH dropout system. Developed to work with SRAM UDH and Full-Mount setups, it also opens the door to single-speed use with the right conversion parts. So while this complete build comes set up as intended from the factory, the frame itself leaves plenty of room for future tinkering if that’s your thing.
This build keeps things sensible in all the right ways. A Shimano Deore 12-speed drivetrain gives you a huge gear range without unnecessary fuss, while Shimano MT420 four-piston brakes bring proper stopping power for steep trail riding. Big-volume Teravail Kessel 2.5” tyres add grip and confidence, and the SR Suntour Zeron36 Boost fork with 140mm travel keeps the front end composed when things get rough.
It’s also been designed with a wide range of riders in mind. Sorceress offers excellent standover clearance across the size range, fits riders from 146cm to 199cm, and includes bottle mounts on every size. XS and SM get one three-pack mount, while MD through XL get a standard bottle mount plus a three-pack.
In short, Sorceress is Surly doing a modern trail hardtail their own way. Steel, clever, adaptable, and ready to get a bit weird out on the trail.
Frame 100% Surly Chromoly steel with modern, hard-charging trail geometry designed around a 140mm suspension fork
Dropouts DUH dropout system compatible with SRAM UDH, Full-Mount, and single-speed setups
Fit Excellent standover clearance and generous dropper insertion for riders from 146cm to 199cm
Mounts Bottle cage mounts on all sizes; one three-pack on XS–SM, one standard plus one three-pack on MD–XL
Fork SR Suntour Zeron36 Boost EQ, 140mm travel
Drivetrain Shimano Deore 12-speed
Brakes Shimano MT420 4-piston hydraulic disc brakes
Tires Teravail Kessel 29 x 2.5” tyres (27.5 x 2.5” on XS)
| Size | X-Small (27.5") | Small (29") | Medium (29") | Large (29") | X-Large (29") |
|---|---|---|---|---|---|
| A. Effective Top Tube | 560 mm | 590 mm | 617 mm | 645 mm | 675 mm |
| B. Stand Over | 730 mm | 763 mm | 782 mm | 796 mm | 809 mm |
| C. Reach | 415 mm | 437 mm | 463 mm | 484 mm | 507 mm |
| D. Stack | 580 mm | 614 mm | 618 mm | 646 mm | 673 mm |
| E. Total Seat Tube Length | 300 mm | 330 mm | 360 mm | 410 mm | 460 mm |
| F. Headtube Length | 95 mm | 95 mm | 100 mm | 130 mm | 160 mm |
| G. Headtube Angle | 64.0° | 65.0° | 65.0° | 65.0° | 65.0° |
| H. Seat Tube Angle | 76.0° | 76.0° | 76.0° | 76.0° | 76.0° |
| I. BB Drop | 55 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| J. BB Height | 303 mm | 314 mm | 314 mm | 314 mm | 314 mm |
| K. Chainstay Length | 410 mm | 429 mm | 429 mm | 429 mm | 429 mm |
| L. Fork Length Axle to Crown | 498 mm | 518 mm | 518 mm | 518 mm | 518 mm |
| M. Fork Offset | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| N. Wheelbase | 1127 mm | 1166 mm | 1193 mm | 1227 mm | 1263 mm |
| Crank Arm Length | 165 mm | 165 mm | 165 mm | 170 mm | 170 mm |
| Handlebar Width | 740 mm | 740 mm | 800 mm | 800 mm | 800 mm |
| Recommended Rider Height | 146 - 159 cm | 156 - 169 cm | 166 - 179 cm | 177 - 189 cm | 187 - 199 cm |
| Stem Length | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
